| 量程 | 500kg/1Klb, 1.2t/2.5Klb, 2.5t/5Klb, 5t/10Klb, 12t/25Klb, 25t/50Klb, 50t/100Klb, 100t/200Klb |
| 灵敏度 | 3mV/V ± 0.25% |
| 零位输出 | Cap.≤ 1.2t/2.5Klb: ≤ ±0.04 mV/V; Cap.≥ 2.5t/5Klb: ≤ ±0.02 mV/V |
| 非线性 | Cap.<1.2t/2.5Klb: < ± 0.05%; Cap.=2.5t-12t/5Klb-25Klb: < ± 0.1% or < ± 0.3%; Cap.=25t/50Klb: < ± 0.3% |
| 重复性 | < ± 0.05% |
| 滞后误差 | Cap.<1.2t/2.5Klb: < ± 0.05%; Cap.=2.5t-12t/5Klb-25Klb: < ± 0.1% or < ± 0.3%; Cap.=25t/50Klb: < ± 0.3% |
| 蠕变 | < ± 0.05% |
| 输入阻抗 | 700Ω ± 10Ω |
| 输出阻抗 | 700Ω ± 5Ω |
| 额定激励电压 | 10V (15V 最大) |
| 绝缘阻抗 | > 2GΩ (50V DC) |
| 补偿温度范围 | –10°C to 50°C/14°F to 122°F |
| Thermal Expansion / Contraction or Minor Misalignment | 500kg-5t/1Klb-10Klb: 2mm; 12t-25t/25Klb-50Klb: 3mm |
| 安全极限载荷 | 150% 满量程 |
| 破坏极限载荷 | 300% 满量程 |
| Lift Protection | 50% 满量程 |
| Side Protection | 50% 满量程 |
| 密封方式 | 焊封 |
| 防护等级 | IP68/IP69K |
